Product Overview
Titanium Optical Frames engineered for wholesale importers, optical brands, and private-label distributors. Built using verified pure titanium and beta-titanium alloys, these frames balance high tensile strength with ultra-low weight (averaging 10g to 18g per frame without lenses). Production utilizes precision CNC milling, laser cutting, and vacuum Ion Plating (IP) to ensure structural integrity, sweat corrosion resistance, and stable color retention across commercial production batches.
Key Features
Ultra-Lightweight Profile
Reduces bridge and ear pressure, maintaining wearer comfort during extended daily use.
01
High Strength-to-Weight Ratio
Withstands daily mechanical flexing without permanent deformation, particularly in beta-titanium temple configurations.
02
Hypoallergenic Material Matrix
Biocompatible metal composition completely eliminates nickel-induced contact dermatitis.
03
Corrosion Resistance
Resists degradation from facial oils, sweat, and saline exposure, preventing green oxidation or pitting on skin-contact points.
04
Precision Tension Hinges
Integrated spring or screwless barrel hinges tested for a minimum of 20,000 open-close cycles without loosening.
05
Materials & Specifications
|
Specification Category |
Technical Details |
Visual/Video Reference Anchor |
|
Primary Material |
Japanese Titanium (CP Titanium Grade 1 / Grade 2) & Beta-Titanium (Ti-15V-3Cr-3Sn-3Al) |
Raw material spectral analysis certification sheet preview |
|
Average Weight |
10.5g – 16.8g (depending on rim style and gauge) |
Precision digital scale weight verification recording |
|
Surface Finishing |
Vacuum Ion Plating (IP Plating), thickness >= 0.3um, salt spray test pass >= 48 hours |
48-hour salt-spray chamber test sample close-up |
|
Lens Compatibility |
Demonstration demo lenses fitted; engineered for Rx optical lenses (CR-39, Polycarbonate, High-Index 1.67/1.74) |
Optical groove depth & bevel fit demonstration |
|
Size Tolerances |
Lens width: +/- 0.3mm; Bridge width: +/- 0.2mm; Temple length: +/- 0.5mm |
Digital caliper measurement verification shot |
Frame Construction
Front Chassis
Formed via high-precision CNC stamping or direct wire-cutting from titanium sheets, ensuring uniform wall thickness around lens grooves (V-groove depth: 0.6mm +/- 0.05mm).
Rimless & Semi-Rimless Mounts
Drilled mounting holes feature micro-chamfering to prevent stress cracks in optical lenses during mounting.
Nose Pad Arms
Pure titanium wire welded via laser micro-spot welding, capable of manual adjustment without weld fracture.
Temple Design
Available in solid sheet temples or elastic beta-titanium wire rods providing 15-25 degrees of outward flex angle for universal head sizing.
Design & Size Options
Silhouette Styles
Full-rim, semi-rimless (supra), rimless 3-piece, and geometric architectural designs.
Standard Caliber Dimensions
Lens Width: 48mm / 51mm / 54mm
Bridge Width: 18mm / 20mm / 22mm
Temple Length: 140mm / 145mm / 150mm
Custom Finishes
Glossy silver, matte gunmetal, rose gold IP, brushed titanium, and dual-tone laser etching.
OEM & ODM Customization
CAD to Prototype
Send STEP/IGES files or physical engineering drawings; 3D resin prototypes delivered within 7 business days.
Laser Branding
Custom logo engraving on temples, inner bridge, or tip ends with adjustable depth settings (0.05mm - 0.1mm).
Color Matching
Custom IP plating matches Pantone or physical sample color swatches with spectrophotometer verification.
Packaging Customization
Branded hard cases, microfiber pouches, outer carton labeling, and customized warranty cards.
Manufacturing & Quality Control
Production Infrastructure: Facility equipped with 40+ CNC milling centers, German laser welding stations, and dedicated IP plating vacuum chambers.
In-House Testing Protocols:
• Torsion Testing: Temples subjected to 10,000 twist cycles at a 30-degree deflection angle.
• Sweat Simulation Test: 48-hour artificial sweat immersion to verify plating adhesion and corrosion thresholds.
• Optical Alignment Inspection: 100% optical projector check for bridge symmetry, pantoscopic tilt, and face-form angle accuracy.
• Compliance Standards: Manufactured under ISO 9001 quality management systems; raw material chemical composition verified via spectral analysis reports prior to blanking.
Applications
Prescription (Rx) Optical Retail
Standardized frames for independent optical stores and multinational eyewear chains.
Corporate & Occupational Eyewear
Lightweight, durable utility frames for corporate employee benefits programs.
Luxury Private Label Collections
High-margin minimalist metal frames designed for fashion brand portfolios.
Direct-to-Consumer (DTC) Brands
Ready-to-scale inventory lines requiring minimal post-factory adjustment.
Packaging & Order Information
|
Logistic Metric |
Master Carton Specification |
|
Inner Packaging |
Individual PE bag, protective sleeve over temples, 12 pcs per inner display box |
|
Master Export Carton |
144 pieces per master carton |
|
Carton Dimensions |
48cm x 32cm x 28cm |
|
Gross Weight |
Approx. 8.5 kg per master carton |
|
Minimum Order Quantity (MOQ) |
300 pieces per style, split across up to 3 color variations (100 pcs/color) |
|
Lead Time |
Samples: 10–14 business days; Bulk production: 35–45 business days |
FAQ
We're well-known as one of the leading titanium optical frames manufacturers and suppliers in China. Please feel free to wholesale customized titanium optical frames at competitive price from our factory. Good service and quality products are available.
